Configuring The System
Setting Up The System
Figure 3.4 FSICEBASE Communication Dialog Box
4. Select USB
NOTE
You can also use the default IP address to connect through TCP/IP.
5. Click OK — the FSICEBASE Configuration Utility connects to the FSICEBASE
6. Click Network tab of FSICEBASE Configuration Utility
7. In Address text box, type the IP address that you want to assign to the FSICEBASE
NOTE
All hosts on a network must have a unique IP address. If you are connecting the
FSICEBASE to a Local Area Network (LAN), consult with your network
administrator to obtain a valid IP address.
8. From Mask combo box, select the subnet mask that you want to assign to the
FSICEBASE
NOTE
All the hosts in a sub-network must have the same subnet mask. For that
reason, if you connect the host computer directly to the FSICEBASE (not
through a LAN), you must ensure that the host computer uses the same subnet
mask as the FSICEBASE.
9. If applicable, in Default Gateway text box, type the IP address of the gateway that the
FSICEBASE should use to connect to a network
10. If applicable, in Broadcast Address text box, type the IP address that you want the
FSICEBASE to use as the broadcast address on the network
NOTE
Freescale Semiconductor
The gateway IP address is required to connect from one LAN to another. The
broadcast IP address is the last IP address in the range of IP addresses on a
network. The broadcast address is reserved by the network to allow a single
host to make an announcement to all hosts on the network. Consult your
network administrator for more information. Normally you should not need to
update this value.
Freescale In-Circuit Emulator Base User Manual, Rev. 1.1
39
